Mass

Curb Weight of Chassis (kg)

8870

Axle load distribution (kg)

Front

4650

Rear

4220

Curb weight (kg)

--

Gross vehicle weight (kg)

25000

MAX Axle Load distribution (kg)

Front

6500

Rear

2*13000

Max. drawing Capacity (kg)

40100

Total weight with trailer (kg)

49000

Max. Load Capacity(kg)

16100

Performances

Min. Steering Diameter (m)

15.6

Max. Speed (km/h)

118

Max. Grade ability (%)

38

Parking Brake Grade Angle (%)

12

Direct Shift Min. Stable Speed (km/h)

35

Direct Shift Accelerate Time (s)

30

Fuel Consumption (l/100km)

38

Fuel Tank Capacity (L)

800

Frame

Type

Side rails, punching and riveted construction

Main Rail section

300x80x8(mm)

Transmission

Model

ETO-20113

Forward Shifts Ratio

iDL=13.94,i1=9.63,

i2=7.60,i3=6.07,

i4=4.85,i5=3.87,

i6=3.06,i7=2.44,i8=1.95,

i9=1.59,i10=1.25,

i11=1.00,i12=0.80

Reverse Shift Ratio

iDPR=18.86,

RL=7.58,RH=3.11

Rear Axle

Type

FAW Single Reduction 457

Reduction Ratio

3.7

Differential lock

Inter-axle differential
